INPUT |
|
Connections |
XLR or RCA |
|
Balanced input Impedance |
94 kΩ |
|
Unbalanced input Impedance |
94 kΩ |
|
Maximum Input Level (input Bal) |
4.8 Vrms |
|
Maximum Input Level (input Unbal) |
2.4 Vrms |
|
Grounding (Two possible modes selectable by
on device menu) |
Grounded : Signal ground connected to earth
Lifted : Separated ground and earth signal |
|
OUTPUT |
|
Power RMS |
200W @ 8Ohm |
|
Power Pic |
850W (max 56.7Vpic 15Apic) |
|
Frequency range (-3dB) |
0.7Hz to 85kHz |
|
Frequency range (+0dB, -0.1dB) |
5Hz to 24kHz |
|
THD+N @ 200W per chanel on 8Ohm from 22Hz to 22kHz |
< 0.004% (-88 dB) @ 1kHz |
|
THD+N unloaded |
< 0.001% (-100dB) @ 1kHz |
|
Clip to Noise Ratio (input Bal) |
-114 dB |
|
Clip to Noise Ratio (input Unbal) |
-113dB |
|
Gain unbalanced |
18.5 dB |
|
Gain Balanced |
24.5 dB |
|
Output impedance |
0.0 Ohm |
|
Damping Factor |
> 3000 |
|
HEADPHONE |
|
Headphone impedance range |
32Ω to 600Ω |
|
Power max per channel |
140 mW |
|
Noise Level |
-96.2 dBu (12 uVrms) |
|
THD+N @ 32Ω, 60mW per channel |
< 0.0009% (-101 dB) @ 1kHz |
|
THD+N @ 600Ω, 60mW per channel |
< 0.0009% (-101 dB) @ 1kHz |
|
TECHNILOGY USED |
|
Unique bias circuit guarantees a constant high bias current in all situations |
|
Real dual mono topology with 6 High resolution MOSFET for a total of 48 Amp. |
|
Three toroidal transformers, one per audio channel of 880VA each and one for digital. |
|
POWER |
|
Nominal line voltage |
115 or 230 V |
|
Input voltage range |
+/-15 % |
|
Maximum power consumption |
950W |
|
Standby consumption |
Less than 1W |
|
SIZE & WEIGHT |
|
Height |
179 mm |
|
Depth |
440 mm |
|
Width |
440 mm |
|
Weight |
36 kg |
|
SAFETY FEATURES |
|
- Non-invasive protection of the audio signal against overload at a current of more than 9 Apic (equivalent to 320W power at 4Ohm) |
|
- Non-invasive protection on the audio signal against DC components on the audio
outputs for all frequencies below 5Hz |
|
- Automatic switching to MUTING if the AC line drops or is interrupted. |
